Big fuse?

By David Robbins; posted November 11, 2011

View Original: Click to zoom, then click to magnify (3648 x 2736) 6108KB




The top piece comes out with a small twist that disengages a pair of brass contacts connected by a wire from what would have been the line. The wide part on the removable piece would probably have shielded the user from burns or contact with the internal connections. See following pictures for the internal connections.
