For the high-voltage aficionados: Maple River sub

By David Dahle; posted September 4, 2011

View Original: Click to zoom, then click to magnify (2272 x 1704) 1231KB




Here's a shot of a major substation - takes one 345kV line, splits it out into 230, 115, and 69kV to cover most of the Red River Valley area. Interesting to be sure, but it doesn't turn my crank much anymore - am getting more interested in the older / more historical transmission lines in the area (13.2 to 69kV).
