Big fluted cast iron transformer

By David Dahle; posted August 2, 2011

View Original: Click to zoom, then click to magnify (1536 x 2048) 933KB




This has to be the biggest cast-iron distribution transformer I've seen (50kVA). On the Alliant Energy system somewhere in southern Minnesota. Looks like the can got a coat of aluminum paint "between assignments". Also note that the can is old enough that it uses pigtail leads instead of terminals. I believe this can is 7200 volts (note the double-petticoat inlet bushing).
