Big Transformer 380 KV to 110 KV and 30 KV Pic4

By Markus Branse; posted September 25, 2009

View Original: Click to zoom, then click to magnify (2816 x 2112) 1597KB




On this pic you can see on the left side the 380 KV Line feeding the transformer, on the right side is beginns the 110 KV line (the insulator chains are shorter). This Transformer also transforms 380 KV into 30 KV, see the lines in front of the transformers going in the ground, the 30 KV line is an underground cable.
