BPA to West Oregon Co-op Sub

By Mike Parker; posted May 23, 2009

View Original: Click to zoom, then click to magnify (3090 x 2048) 4624KB




The input side of the Timber Jct., OR. Bonneville Power Authority to West Oregon Electric Co-op substation. 120,000 volts from BPA enters the sub. on the pyrex disk insulators and makes it's way to a big monster transformer that steps the voltage down to 34,500 for the transmission lines of the co-op.
