Glines Canyon substation

By Joel Goff; posted October 19, 2008

View Original: Click to zoom, then click to magnify (2272 x 1704) 999KB




this pole carries power and control wires up the hill to the dam gates (i think). I've never seen this kind of setup before. Top arm carries the 4 wire, three phase power for motors. Lower arm has a triplex (probably 120 / 240v for lighting) and control wires.
