Double Circuit 161Kv line near Jackson, TN

By Eian Greene; posted January 17, 2008

View Original: Click to zoom, then click to magnify (2141 x 1944) 479KB




This line was re-built following a major tornado in the area a few years back, as well as to anticipate rapid growth in the area. The old line was a single circuit line on the typical TVA tower type with horizontally stacked wires. The line leads to a substation roughly a mile south of here. The line allows the substation to tap either direction of a single circuit line about 1/2 mile north (behind camera) allowing for greater reliability.
