Small substation
By Joel Goff; posted May 18, 2006
View Original: Click to zoom, then click to magnify (1200 x 1600) 924KB
|
small sub that feeds some radio towers. pri voltage is 55kv secondary is 7200. there are only 2 phases on the outgoing side. Here's the incoming 55kv lines |
