Mock-up: 400/220 kV transformer

By Zoltán Drinóczi; posted November 10, 2005

View Original: Click to zoom, then click to magnify (1024 x 768) 304KB




This is a moch up from a transformer from either sumstation.

This is a 3 phase oil one, about 800 MVA, 1200 tons weigh, 150 tons of oil, and 350 tons of paper, the other is the copper and house. It's value is about $4 million USD.
